rt-Inverto PREMIUM-Single Universal LNB
(0 Reviews)
Sold By:
Inhouse product
Inhouse product
Price:
KD2.900
/Pc
Share:
Sold By
STAR ALFA Co.Electric & Electronic Appliances
(1 customer reviews)
Top Selling Products
-
rt-Inverto PREMIUM-Quattro LNB
KD9.900 -
Technical Visit
KD5.000 -
TRIAX-Universal QUATTRO LNB
KD9.000
Main Features:
- Low Phase Noise, DVB-S2 (HD and UHD) compliant
- Low Noise Figure
- Low power consumption
- High Cross Polarization Isolation
- High Frequency stability
Technical specifications
- Input frequency range 10.7 GHz ~ 12.75 GHz
- Output frequency range 950 MHz ~ 1950 MHz
- Low band LO frequency 9.75 GHz
- High band LO frequency 10.6 GHz
- Noise figure 0.7 dB typ. (1 dB max.)
- LO frequency accuracy @ 25° C ±400 kHz max.
- LO temperature drift ±800 kHz max.
- LO phase noise @ 10 kHz -90 dBc/Hz max.
- Conversion gain 55 dB min.
- Gain ripple (over 26 MHz bandwidth) ±0.6 dB
- Gain variation (over full band) ±4 dB
- Image rejection 40 dB min.
- 3th order intermodulation - ICP3 10 dBm typ.
- 1 dB compression point (@ output) 0 dBm min.
- Cross polarization isolation 22 dB min.
- Control signal Ca (V) 10.0 V ~ 14.0 V
- Control signal Cb (H) 16.0 V ~ 20.0 V
- Control signal Cc (band switching) 22 kHz ±4 kHz
- Output VSWR 2.3 : 1
- In band spurious level -60 dBm max.
- Current consumption 210 mA max. @ 11 VDC ~ 20 VDC
- Operating temperature -30 °C ~ +60 °C
- Output impedance (LNB2) 75 Ω
- Output connector type F-type (female)
- Dish F/D ratio 0.6
- Weight 299 g
