rt-Inverto PREMIUM-Quattro LNB
(0
reviews)
Inhouse product
Price
د.ك9.990
/Pc
Share
Top Selling Products
Reviews & Ratings
0
out of 5.0
(0
reviews)
There have been no reviews for this product yet.
Main Features:
- Low Phase Noise, DVB-S2 (HD and UHD) compliant
- Low Noise Figure
- Low power consumption
- High Cross Polarization Isolation
- High Frequency stability
Technical specifications | |
|---|---|
| Input frequency range | 10.7 GHz ~ 12.75 GHz |
| Output frequency range | 950 MHz ~ 1950 MHz |
| Low band LO frequency | 9.75 GHz |
| High band LO frequency | 10.6 GHz |
| Noise figure | 0.7 dB typ. (1 dB max.) |
| LO frequency accuracy @ 25° C | ±400 kHz max. |
| LO temperature drift | ±800 kHz max. |
| LO phase noise @ 10 kHz | -90 dBc/Hz max. |
| Conversion gain | 55 dB min. |
| Gain ripple (over 26 MHz bandwidth) | ±0.6 dB |
| Gain variation (over full band) | ±4 dB |
| Image rejection | 40 dB min. |
| 3th order intermodulation - ICP3 | 10 dBm typ. |
| 1 dB compression point (@ output) | 0 dBm min. |
| Cross polarization isolation | 22 dB min. |
| Control signal Ca (V) | 10.0 V ~ 14.0 V |
| Control signal Cb (H) | 16.0 V ~ 20.0 V |
| Control signal Cc (band switching) | 22 kHz ±4 kHz |
| Output VSWR | 2.3 : 1 |
| In band spurious level | -60 dBm max. |
| Current consumption | 210 mA max. @ 11 VDC ~ 20 VDC |
| Operating temperature | -30 °C ~ +60 °C |
| Output impedance (LNB2) | 75 Ω |
| Output connector type | F-type (female) |
| Dish F/D ratio | 0.6 |
| Weight | 299 g |
| Logistical info | |
| Packaging dimensions (W x D x H) | 13.9 cm x 12.3 cm x 7.1 cm |
| Packaging weight | 0.368 kg |
| Quantity per Carton | 20 pcs |
| Carton dimensions (W x D x H) | 37.5 cm x 29.0 cm x 26.0 cm |
| Carton weight | 7.9 kg |
| Quantity per pallet | 36 ctns/plt, 48 ctns/plt |
